Description
A rupture disc holder with high-strength steel hex-head bolts to ensure precise loading and sealing of HPX rupture discs.
Optimize flow, secure seals, guarantee correct disc orientation, and prevent disc fragmentation with an HPX-PT pre-torqued holder. The HPX-PT holder allows the disc to be properly tightened in the shop using the recommended torque levels before the complete assembly is installed between the flanges in the process relief system
Get a consistently accurate rupture disc installation with the HPX-PT pre-torqued holder.
Before installation, you will install and tighten the disc in your shop. Then, all you need to do is complete the assembly between the flanges in the process relief system.
The HPX-PT pre-torqued holder incorporates high-strength steel hex-head bolts for precise rupture disc loading and sealing.
The HPX-PT pre-torqued holder:
Allows precise torque loading in the controlled environment of a shop before installation, simplifying final installation.
Maintains precise rupture disc loading, even where poor flange alignment and gasket cold flow can be a problem, improving performance.
The pre-torqued holder bolts are protected with a coating to prevent wear, corrosion, seizing, and galling of the bolts, reducing maintenance costs.
Common installations:
Process equipment with glass-lined or fluoropolymer-lined flanges that cannot provide enough compression to seal the rupture disc in the holder.
Where piping arrangements restrict access, preventing correct torque loading of the flange fasteners.
Processes that require regular removal and inspection of the rupture disc and holder assembly.
Applications that require leak testing of the rupture disc assembly before installation in the piping system.
Available options:
Alternative height.
Gauge taps on the holder outlet.
Flange bolts and nuts, alloy steel or 316 stainless steel.
J-hook on the holder inlet.
Increased corrosion resistance through fluoropolymer coatings or TANTALINE treatment.
Please note that pre-torqued holder designs may vary by bolt class and size.
Nominal Size Range: 1″ – 12″ (25 mm – 300 mm)
Burst Pressure Range: N/A
Maximum Recommended Operating Ratio: N/A
Seat Configuration: Flat Seat
Service: Liquid or gas
Compatible with the BDI Alarm System?: Available to comply with ASME Section VIII Division 1, but must also be used with an HPX rupture disc that complies with ASME Section VIII Division 1.
ASME Code Symbol Stamp Available?: Available to comply with ASME Section VIII Division 1, but must also be used with an HPX rupture disc that complies with ASME Section VIII Division 1.
